Technical Characteristics

• Overall Length

  3.190 inches nominal

• Overall Width

  0.330 inches nominal

• Board Accommodated Length

  2.481 inches nominal

• Board Accommodated Width

  0.054 inches minimum and 0.071 inches maximum

• Mating End Quantity

  1

• Contact Surface Treatment

  gold

• Insert Material

  plastic diallyl phthalate

• Terminal Type

  tab,solder lug

• Insert Material Document And Classification

  mil-p-19883,ty gdi-30 mil spec single material response

• Included Contact Quantity

  30

• Precious Material And Weight

  0.030 gold grains,troy

• Precious Material

  gold

• Body Style

  straight edge type w/mounting flange

• Distance Between Mounting Facility Centers

  2.937 inches nominal

• Contact Position Arrangement Style

  2 rows of independent contacts inserted board

• Contact Removability

  nonremovable

• Terminal Location

  back

• Contact Material

  copper alloy

• Included Contact Type

  leaf spring

• Precious Material And Location

  contact surfaces gold
